Multi-Layer PA Tube

Language Translator

Multi-Layer PA Tube

Minimum Order:	100Meter/Meters
Export Ratio:	61% - 70%
Unit Price:	1.5-2/Meter
Samples:	Free
Place of Region:	CN
Payment Terms:	L/C,T/T
Price Terms:	EXW
Delivery Port:	Shanghai,Ningbo
Delivery Time:	10days
Market Type:	After Market
Packing:	Uaually Package
Current Export Market:	North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East

Product Details

Product Name:

Multi-Layer PA Tube

Product Attribute:

Material:Plastic

Size:3,6,8,10,12,14,16mm

Color:Black

Application:

any cars

Product Description:

Details:

We recent development of automotive fuel systems:having imported advanced multi-layer extrusion lines and technology.The tube has excellent resistance to permeation,oil,corrosion and anti-aging.It applies to the mixtrue of fuel and ethanol,which can meet Euro IV.It is a kind of lightweight,high performance and environmentally friendly tube widely used in automotive fuel system.

Five-layer tube with OD6mm,8mm,10mm etc.
Out Layer PA12
Tie Layer
Barrier Layer EVOH
Tie Layer
lnner Layer PA12

Executive Standard:SAE J2260 QC/T798-2008
Working temperature-40~115
Continuous working temperature90
Working pressure:0.7MPa

No		Test project	unit	requirement
1	Burst strength	burst strength in room temperature	MPa	5.6
1	Burst strength	burst strength in High temperature	MPa	2.1
2	Bending performance	min.Bending radius	mm	Meet QCT-798-2008 requirements
		Resistance to bending deformation	--
		Burst strength after bending	MPa	5.6
3	Resistance to ZnCl2	apperance	--	no cracking with oyter and inner tube surface
3	Resistance to ZnCl2	burst strength in room temperature	MPa	4.2
4	Cold-temp erature impact	apperance	--	no cracking in apperacnce
4	Cold-temp erature impact	burst strength in room temperature	MPa	4.2
5	performance of permeation resistance	permeation rate	g/m.d	0.05
		length change rate	--	-1%~+1%
		burst strength in room temperature	MPa	5.6
6	yield stress	parallel Extrusion direction	N/m	24
	yield stress	vertical Extrusion direction		25
	elongation	Extrusion direction	%	170
	elongation	vertical direction	%	170
7	Performance of fuel resistance	apperance	--	no cracking in apperacnce
		Low-temperature impact	--	no cracking in apperacnce
		burst strength in room temperature	MPa	5.6
		Stress yield at Extrusion direction	N/m	20
		Elongation at Extrusion direction	%	150
		layer adhesive force		no clear delamination phenomenon between cutting layers
