Fuel Line Quick Connector Of 6.3 Straight To Hose ID 6mm
Material:Plastic
Shape :Square
Color:Black
Gender :Female
ANY CARS
Item:Fuel line quick connector of 6.3mm straight,to hose ID 6mm Material:PA12+30% GF Size:Ø6.30mm-Ø6.35mm 180° Tube ID x OD:6X8mm only Quick connector assembly & disassembly operations method: 1.Eternal quick connector is made up of body,in O-ring,out O-ring,spacer ring,securing ring and locking spring. 2.Insert the mating tube end piece to connector,due to the function of flexible locking spring and snap fastener,they are joined together,then pull back to assure a complete connection so that quick connector coupling can work well. 3.While in disassembly,firstly push in male end piece,then press locking spring ends till expansion from the middle,the connector can be easily pulled out. 4.Lubricated with SAE 30-weight oil before re-connecting. Independent development: A high heat change resistant nylon and its preparation method patent number:201110107011.6
